Problem set 2: Buddy allocation and wait queues

A. Kernel buddy allocator

The existing Chickadee allocator, kallocpage(), can only allocate memory in units of single pages, and it cannot free memory. That’s bad!

Freeing memory is not too hard to support; a singly-linked free list of pages could work. But we seek an efficient allocator for variable-sized allocations. This is important for kernel functionality; for instance, Chickadee kernel stacks are limited to 4000 bytes or so because struct procs are allocated in units of single pages.

In this part, you will therefore implement a buddy allocator for kernel memory. Complete the following functions in k-alloc.cc:

kalloc and kfree are the malloc and free equivalents. init_kalloc() should perform any initialization necessary so that the allocator has access to all available physical memory (i.e., physical memory with type mem_available in physical_ranges), and test_kalloc() should perform tests rigorous enough to convince the course staff that your allocator works correctly.

Then replace your kallocpage() implementation with this:

x86_64_page* kallocpage() {
    return reinterpret_cast<x86_64_page*>(kalloc(PAGESIZE));
}

and make sure Chickadee still works.

Buddy allocation

The buddy allocation algorithm is one of the oldest general algorithms for memory allocation. (It was invented in 1963!) Buddy allocation supports efficient splitting (breaking large contiguous blocks of free memory into smaller pieces) and coalescing (merging adjacent free blocks into larger contiguous blocks).

Buddy allocation is based on powers of 2 called orders. An allocation request of size \(s\) uses a block of size \(2^o\) and order \(o\), where

\[o = \left\lceil \log_2 s \right\rceil.\]

For example, an allocation request of size 4095 will use a block of size 4096 and order 12, but an allocation request of size 4097 will use a block of size 8192 and order 13. The physical address of a block of order \(o\) is always a multiple of \(2^o\).

Allocation splits large blocks until there’s a free block with the right size.

  1. Let o be the desired order for the allocation.
  2. Find a free block with order o. If found, return that block.
  3. Otherwise, find a free block with order x > o, minimizing x. If found:
    1. Split the block in two, creating two free blocks with order x-1. These two blocks are called order-(x-1) buddies because they are adjacent blocks with order x-1, and the address of one is easily calculated from the address of the other.
    2. Repeat step 2.
  4. If there’s no larger free block, the allocation fails: return nullptr.

Freeing coalesces freed buddies whenever possible. This can create large contiguous free blocks very efficiently.

  1. Let o be the order of the freed block.
  2. Check whether the freed block’s order-o buddy is also completely free. If it is:
    1. Coalesce the freed block and the buddy into a single free block of order o + 1.
    2. Repeat step 2.

Buddy allocators have low external fragmentation (unusable space between allocated blocks) because they aggressively coalesce freed memory into larger blocks. Their internal fragmentation (unused space inside allocated blocks) is at most 50%. Many real-world allocators use buddy allocation, often coupled with other techniques (for, e.g., efficient multicore support); for instance, both Linux and jemalloc use buddy allocation.

Designing your allocator

Your buddy allocator will use two constant parameters, min_order and max_order, which are the minimum and maximum orders the allocator supports. Your allocator will have min_order 12, so every allocation request will use at least a page of memory. (Note that this increases the maximum internal fragmentation.) It should have max_order at least 21, allowing it to support contiguous allocations of up to 2MiB.

Your allocator will maintain at least the following state.

The pages array lets you quickly check whether a buddy is free. The free lists lets you quickly find a free block of a given order. Both these operations are O(1), and there are a constant number of orders, so both kalloc and kfree should take O(1) time.

You own the definition of the page structure and the pages array (and you can call the array something else if you want). You will add more information to the array later.

Hints

We’ve added some useful math functions to lib.hh. You might especially like msb(x), which returns the index of the most significant 1 bit in x plus one. (For example, msb(1) == 1; msb(4095) == 12; msb(4096) == 13. As a special case, msb(0) == 0.) There are also roundup_pow2 and rounddown_pow2.

We’ve also added a generic doubly linked list type in k-list.hh. This would be useful for building free lists; or you can build your own.

Make sure you add assertions to your code. You’ll probably also want some helper functions, such as a function that returns a block’s order-o buddy, and a function that confirms that a physical address is valid as an order-o block.

Slab allocation (advanced optional work)

This style of buddy allocator is great for large objects, but because it relies on a pages array with information about each min_order block, it doesn’t scale to small allocation sizes (e.g., 64-byte allocations). For smaller allocations, most systems switch to another allocation strategy, such as slab allocation. Design and implement such an allocator.

B. Exit

Implement the sys_exit system call.

Preparation

  1. Merge our latest code via git pull handout master or equivalent. (You want 91a2b361336b917253082ea3013e4b2ccf228a1b or later.) Make sure your kernel still runs!
  2. Change process_setup to map the console at address 0xB8000 (i.e., ktext2pa(console)) in the initial process by default.

Implementing exit

Your initial version of exit should do the following:

When you’re done, make run-allocexit should show an endless explosion of different colors as new processes are created and old processes exit (freeing memory). There should be no leaks. (A leak will appear as a “free” physical page—a period in the physical page map—that is never reused.)

To make exit work in Chickadee, you’ll need to obey several invariants.

And you’ll probably need to change your code for sys_fork, and possibly other code, to avoid leaks.

C. Sleep

Implement the sys_msleep system call, which sleeps (i.e., does not return to its caller) until at least N milliseconds have passed.

For now, sys_msleep should return 0. In a future part, you will add support for system call interruption, and sys_msleep will return the error constant E_INTR if it is interrupted.

To add the system call, you’ll add a system call number to lib.hh, complete the user-level wrapper in p-lib.hh, and add an implementation case to proc::syscall. The kernel implementation will use the kernel’s ticks variable, which is a global variable incremented by the timer interrupt handler every 0.01 seconds. (So you’ll want to round the sleep argument up to the nearest multiple of 10 milliseconds.)

Use make run-testmsleep to test your work.

Warning! If initial implementation fails, see Lecture 7.

D. Parent processes

Implement parent processes and the sys_getppid system call.

In Unix, every process has a parent; the getppid system call returns the parent’s process ID. If a parent exits before a child, the child is reparented to have parent process ID 1. Process ID 1 is special; that process, called the init process, corresponds to an unkillable kernel task. Chickadee follows this design.

First implement the easy cases. These can be completed before you figure out performance and synchronization.

Use make run-testppid to test your work. You should succeed through the “tests without exit succeeded” line. (The test program depends on a working sys_msleep implementation from Part C, though the rest of the code in this part is independent of sys_msleep.)

Implementation note: As you add content to struct proc, you may need to update your pset 1 stack canary code, especially if you hard-wired offset constants into assembly. It would be OK to disable your stack canary code for now (though as you make struct proc bigger and add kernel functionality, the stack canary might be useful!).

Then, implement exit and process reparenting.

Write up in pset2answers.md:

Performance

When a process exits, the kernel must reparent its children. This should take \(O(C)\) time for a process with \(C\) children (rather than, say, \(O(P)\) time, where \(P\) is the total number of processes in the system).

Implementing \(O(C)\) exit will require tracking additional per-process metadata, which your writeup should describe.

Synchronization

Chickadee processes so far have been quite isolated: no action performed by one running process ever accessed another running process’s state. Here is a visualization of kernel programming under these conditions [1]:

Teletubbies

Starting in this portion, actions taken by one running process can affect other running processes. And Chickadee is a multiprocessor kernel, so these processes might be running simultaneously, in kernel mode, on different CPUs. What happens if one process exits while one of its children is calling sys_getppid? What happens if a process and one of its children are exiting simultaneously? It is incredibly important to implement correct synchronization or the kernel could break. Here is a visualization of kernel programming under these conditions [2]:

Hellatubbies

Correct synchronization requires planning ahead. A good approach is to write down synchronization invariants: what locks are required to examine or modify particular data items? Chickadee already has a couple synchronization invariants; you will now start adding your own.

The simplest invariants are usually the most coarse-grained. (Early multicore operating systems used a giant lock approach, or “big kernel lock,” in which the entire kernel was protected by a single lock!) For instance, perhaps any change to the process hierarchy should require the ptable_lock.” Finer-grained invariants are also possible when you reason about state by purpose. For example, a global process_hierarchy_lock could protect access to the process hierarchy (that is, process parent and child links). This is somewhat more scalable than using ptable_lock for everything since some accesses to ptable don’t require the process_hierarchy_lock, and some accesses to the process hierarchy don’t require the ptable_lock. Or you can have a lock per process, if you can make it work. (For what it’s worth, Linux uses a global “task list lock”, which is like a process_hierarchy_lock, but implements it as a readers-writer lock rather than a spinlock. The super-scable sv6 operating system uses a lock per process. Remember that correctness matters way more than performance for us nows.)

Describe your synchronization invariants in your writeup.

E. Wait and exit status

Implement the sys_waitpid system call and the exit status argument to sys_exit. Use the p-testwaitpid and p-testzombie programs to check your work.

Specification

Chickadee sys_waitpid implements a subset of the Unix waitpid behavior. It implements blocking and polling, exit status return, and selective waiting, but does not (yet) implement signal reporting, job control, or process groups.

pid_t sys_waitpid(pid_t pid, int* stat = nullptr, int options = 0)

Implementation notes

Remember that system calls and assembly functions can define their own calling conventions. We recommend that the kernel use another register to return the exit status to the user-level wrapper, such as %rcx. The user-level wrapper, rather than the kernel, will move the resulting value to *stat. This sidesteps issues with cross-context memory checking (the kernel must validate any pointer provided by untrusted user code). Look to p-lib.hh for examples of how to associate registers with values.

sys_waitpid will change the mechanism for freeing exited processes. Exited processes still become non-runnable, but their exit status must be preserved, and their PIDs not reused, until their parent calls sys_waitpid. You’ll need to add some stuff to struct proc. You’ll also be able to remove stuff from cpustate::schedule that you added in Part B (what?).

The p-testwaitpid program tests W_NOHANG functionality before it tests blocking functionality, so you can test a simple, nonblocking version of the system call first. The p-testzombie program also tests important sys_waitpid functionality.

Since waitpid involves cross-process communication, it requires synchronization. Your writeup should describe your synchronization invariants.

F. True blocking

Chickadee now has two blocking system calls, sys_msleep and sys_waitpid, but (unless you were real ambitious) neither of these system calls has a truly blocking implementation. User processes calling these system calls appear to block, but their corresponding kernel tasks remain runnable and repeatedly yield. This is easy to program but inefficient. It’s far better for the kernel tasks corresponding to blocked processes to become non-runnable.

The problem can be quantified. We added a counter to each process that counts how many times that process resumes. With a proc::yield–based implementation of sys_msleep, the p-testmsleep program results in more than 100,000 total resume events!

In this problem you will add true blocking to Chickadee, while avoiding the dreaded sleep-wakeup race condition, also known as the lost wakeup problem.

Lost wakeups in sys_waitpid

To understand lost wakeups, consider broken pseudocode like this for waitpid:

waitpid(proc* parent, ...) {
    ...
    while (/* no child is ready */) {
        parent->state_ = proc::blocked;
        parent->yield();
    }
    ...
}

exit(proc* p, ...) {
    ...
    proc* parent = ptable[p->ppid_];
    // wake up the parent; locking elided
    parent->state_ = proc::runnable;
    cpus[parent->cpu_].enqueue(parent);
    ...
}

Looks OK, right? waitpid blocks by setting proc::state_ to blocked; exit unblocks the parent by setting its state_ to runnable and enqueuing it on its home CPU. Well, it’s not OK. Consider the following sequence of events, where the parent calls waitpid on one CPU while one of its children calls exit on another:

waitpid:                                exit:
                                            parent->state_ = proc::runnable;
    parent->state_ = proc::blocked;
    parent->yield();
    CPU dequeues `parent`, doesn’t run
    it
                                            cpus[0].enqueue(parent);
    ...later, CPU dequeues `parent`
    again, but again doesn’t run it,
    since its state_ is still blocked!

The parent blocks indefinitely, even though it has a child with status ready to collect. There’s a race condition between sleeping (waitpid) and wakeup (exit). Correctness requires that when wakeup and sleep occur simultaneously, wakeup must win. But there’s nothing in the code to enforce that order.

Locks to the rescue: the sleeping and wakeup code must synchronize using some lock. The sleeping code assigns proc::state_ to blocked with the lock held, and validates that it should go to sleep before releasing that lock. But what lock?

Wait queues

It’s obvious in exit what process to wake: it is the unique parent process of the exiting process. Blocking in sys_msleep is different: which processes should the timer interrupt wake up? We need a queue of processes waiting for a timer interrupt.

Operating system kernels are full of different conditions that must be awaited, so kernels provide data types that simplify the process of waiting. You’ll implement a wait queue data type. To introduce a condition, the kernel declares a wait_queue. A sleeping kernel thread initializes and manipulates a waiter object, in the following way:

waiter w(this);
while (1) {
    w.prepare(&waitq);
    if (this process should wake up) {
        break;
    }
    w.block();
}
w.clear();

The wait_queue object contains a spinlock for synchronization and a list of blocked waiters. The waiter object stores the wait queue and the blocked process, allowing wakeup code to find and wake up every waiting process.

Read more about wait queues in the Lecture 8 notes.

Implementation

G. System call interruption

In the last part of the problem set, you will implement system call interruption. Specifically, if a child exits while a parent is blocked in sys_msleep, then the parent’s sys_msleep should return early with the E_INTR return code.

Use make run-testeintr to check your work.

Note: This part of the problem set models the Unix signal mechanism. Unfortunately, as we discussed in CS61, the signal mechanism has inherent race conditions that are difficult to solve. It is OK for your interruption mechanism to have similar race conditions as Unix signals. For instance:

However, if a child exits after sys_msleep decides to block, then sys_msleep must return early with the E_INTR return code.

Hint: You may need to add extra member variables to struct proc.

Turnin

Fill out psets/pset2answers.md and psets/pset2collab.md and push to GitHub. Then submit on the grading server.

Intermediate checkin 1: Turn in part A by 11:59pm Monday 2/12.
Intermediate checkin 2: Turn in parts B–D by 11:59pm Monday 2/19.
Final checkin: Turn in all parts by 11:59pm Monday 2/26.
